scc::sc_register_masked< DATATYPE, WRMASK, RDMASK > Class Template Reference
#include <register.h>
Inheritance diagram for scc::sc_register_masked< DATATYPE, WRMASK, RDMASK >:
Collaboration diagram for scc::sc_register_masked< DATATYPE, WRMASK, RDMASK >:
Public Member Functions | |
| sc_register_masked (sc_core::sc_module_name nm, DATATYPE &storage, const DATATYPE reset_val, resetable &owner) | |
| Public Member Functions inherited from scc::impl::sc_register< DATATYPE > | |
| sc_register (sc_core::sc_module_name nm, DATATYPE &storage, const DATATYPE reset_val, resetable &owner, DATATYPE rdmask=get_max_uval< DATATYPE >(), DATATYPE wrmask=get_max_uval< DATATYPE >()) | |
| the constructor | |
| ~sc_register ()=default | |
| desctructor | |
| bool | is_trace_enabled () const override |
| returns of this component shall be traced | |
| size_t | size () const override |
| get the size of this register in bytes | |
| void | reset () override |
| reset the register | |
| bool | write (const uint8_t *data, size_t length, uint64_t offset, sc_core::sc_time &d) override |
| write function from resource_access_if | |
| bool | read (uint8_t *data, size_t length, uint64_t offset, sc_core::sc_time &d) const override |
| read function from resource_access_if | |
| bool | write_dbg (const uint8_t *data, size_t length, uint64_t offset=0) override |
| debug write function from resource_access_if | |
| bool | read_dbg (uint8_t *data, size_t length, uint64_t offset=0) const override |
| debug read function from resource_access_if | |
| operator DATATYPE () const | |
| cast operator to get underlying storage | |
| DATATYPE | get () const |
| get the underlying storage | |
| void | put (DATATYPE data) const |
| write to the underlying storage | |
| this_type & | operator= (DATATYPE other) |
| assignment operator | |
| this_type & | operator|= (DATATYPE other) |
| unary or | |
| this_type & | operator&= (DATATYPE other) |
| unary and | |
| void | set_read_cb (std::function< bool(const this_type &, DATATYPE &)> read_cb) |
| set the read callback | |
| void | set_read_cb (std::function< bool(const this_type &, DATATYPE &, sc_core::sc_time &)> read_cb) |
| set the read callback | |
| void | set_write_cb (std::function< bool(this_type &, const DATATYPE &)> write_cb) |
| set the write callback | |
| void | set_write_cb (std::function< bool(this_type &, const DATATYPE &, sc_core::sc_time &)> write_cb) |
| set the write callback triggered upon a write request | |
| void | trace (sc_core::sc_trace_file *trf) const override |
| trace the register value to the given trace file | |
| Public Member Functions inherited from scc::resource_access_if | |
| virtual bool | write (const uint8_t *data, std::size_t length, uint64_t offset, sc_core::sc_time &d)=0 |
| bool | write (const uint8_t *data, std::size_t length, uint64_t offset=0) |
| virtual bool | read (uint8_t *data, std::size_t length, uint64_t offset, sc_core::sc_time &d) const =0 |
| bool | read (uint8_t *data, std::size_t length, uint64_t offset=0) const |
| virtual bool | write_dbg (const uint8_t *data, std::size_t length, uint64_t offset=0)=0 |
| debug write to the resource | |
| virtual bool | read_dbg (uint8_t *data, std::size_t length, uint64_t offset=0) const =0 |
| debug read the data from the resource | |
Additional Inherited Members | |
| Public Types inherited from scc::impl::sc_register< DATATYPE > | |
| using | this_type = sc_register<DATATYPE> |
| Public Attributes inherited from scc::impl::sc_register< DATATYPE > | |
| cci::cci_param< bool > | enable_tracing |
| const DATATYPE | res_val |
| the reset value | |
| const DATATYPE | rdmask |
| the SW read mask | |
| const DATATYPE | wrmask |
| the SW write mask | |
Detailed Description
template<typename DATATYPE, DATATYPE WRMASK = impl::get_max_uval<DATATYPE>(), DATATYPE RDMASK = impl::get_max_uval<DATATYPE>()>
class scc::sc_register_masked< DATATYPE, WRMASK, RDMASK >
class scc::sc_register_masked< DATATYPE, WRMASK, RDMASK >
alias class to map template argument read an write mask to constructor arguments
Definition at line 470 of file register.h.
Constructor & Destructor Documentation
◆ sc_register_masked()
template<typename DATATYPE, DATATYPE WRMASK = impl::get_max_uval<DATATYPE>(), DATATYPE RDMASK = impl::get_max_uval<DATATYPE>()>
|
inline |
Definition at line 472 of file register.h.
The documentation for this class was generated from the following file:
- /home/eyck/Projects/MINRES/SystemC-Components/src/components/scc/register.h
