| | memory (const sc_core::sc_module_name &nm) |
| void | set_operation_callback (std::function< int(memory< SIZE, BUSWIDTH > &, tlm::tlm_generic_payload &, sc_core::sc_time &delay)> cb) |
| | allows to register a callback or functor being invoked upon an access to the memory
|
| void | set_dmi_callback (std::function< bool(memory< SIZE, BUSWIDTH > &, tlm::tlm_generic_payload &, tlm::tlm_dmi &)> cb) |
| | allows to register a callback or functor being invoked upon a direct memory access (DMI) to the memory
|
| void | map_host_memory (uint64_t base, uint64_t size, uint8_t *ptr) |
| | maps a given memory into the address range of the TLM memory
|
| void | unmap_host_memory (uint64_t base, uint64_t size) |
| | unmpas a host memory mapped into the address range of the TLM memory
|
| int | handle_operation (tlm::tlm_generic_payload &trans, sc_core::sc_time &delay) |
| | ! handle the memory operation independent on interface function used
|
| bool | handle_dmi (tlm::tlm_generic_payload &gp, tlm::tlm_dmi &dmi_data) |
| | handle the dmi functionality
|
|
| tlm::scc::target_mixin< tlm::tlm_target_socket< BUSWIDTH > > | target {"ts"} |
| | the target socket to connect to TLM
|
| cci::cci_param< bool > | allow_dmi {"allow_dmi", true, "Allow DMI accesses to this memory if set"} |
| | allow DMI accesses
|
| cci::cci_param< delay_type > | rd_resp_delay {"rd_resp_delay", delay_spec_type<USE_CYCLES>::get_default_val()} |
| | read response delay in cycles if USE_CYCLES==true else in sc_core::sc_time
|
| cci::cci_param< delay_type > | wr_resp_delay {"wr_resp_delay", delay_spec_type<USE_CYCLES>::get_default_val()} |
| | write response delay in cycles if USE_CYCLES==true else in sc_core::sc_time
|
| std::function< int(memory< SIZE, BUSWIDTH > &, tlm::tlm_generic_payload &, sc_core::sc_time &delay)> | operation_cb |
| std::function< bool(memory< SIZE, BUSWIDTH > &, tlm::tlm_generic_payload &, tlm::tlm_dmi &)> | dmi_cb |
template<unsigned long long SIZE, unsigned BUSWIDTH = LT, unsigned PAGE_ADDR_BITS = 24, bool USE_CYCLES = false>
class scc::memory< SIZE, BUSWIDTH, PAGE_ADDR_BITS, USE_CYCLES >
simple TLM2.0 LT memory model
This model uses the util::sparse_array as backing store. Therefore it can have an arbitrary size since only pages for accessed addresses are allocated. it is possible to map specific host memory ranges to a target memory range. For this the scc::host_mem_map_extension hs to be used in conjunction with the TLM_IGNORE_COMMAND. The extension carries the pointer to the host memory to be used while the generic payload address and length indicate the size of the memory block
TODO: add some more parameters to configure allowed access types (rw, read only)
- Template Parameters
-
| SIZE | size of the memery |
| BUSWIDTH | bus width of the socket |
Definition at line 70 of file memory.h.
template<unsigned long long SIZE, unsigned BUSWIDTH, unsigned PAGE_ADDR_BITS, bool USE_CYCLES>
| scc::memory< SIZE, BUSWIDTH, PAGE_ADDR_BITS, USE_CYCLES >::memory |
( |
const sc_core::sc_module_name & | nm | ) |
|
constructor with explicit instance name
- Parameters
-
implementation details ///////////////////////////////////////////////////////////////////////////
Definition at line 197 of file memory.h.
template<unsigned long long SIZE, unsigned BUSWIDTH = LT, unsigned PAGE_ADDR_BITS = 24, bool USE_CYCLES = false>
| void scc::memory< SIZE, BUSWIDTH, PAGE_ADDR_BITS, USE_CYCLES >::map_host_memory |
( |
uint64_t | base, |
|
|
uint64_t | size, |
|
|
uint8_t * | ptr ) |
|
inline |
maps a given memory into the address range of the TLM memory
- Parameters
-
| base | base address where the memory shall be mapped |
| size | size of the memory range to map |
| ptr | pointer to the mapped host memory |
Definition at line 131 of file memory.h.
template<unsigned long long SIZE, unsigned BUSWIDTH = LT, unsigned PAGE_ADDR_BITS = 24, bool USE_CYCLES = false>
| void scc::memory< SIZE, BUSWIDTH, PAGE_ADDR_BITS, USE_CYCLES >::set_dmi_callback |
( |
std::function< bool(memory< SIZE, BUSWIDTH > &, tlm::tlm_generic_payload &, tlm::tlm_dmi &)> | cb | ) |
|
|
inline |
allows to register a callback or functor being invoked upon a direct memory access (DMI) to the memory
- Parameters
-
| cb | the callback function or functor |
Definition at line 109 of file memory.h.
template<unsigned long long SIZE, unsigned BUSWIDTH = LT, unsigned PAGE_ADDR_BITS = 24, bool USE_CYCLES = false>
| void scc::memory< SIZE, BUSWIDTH, PAGE_ADDR_BITS, USE_CYCLES >::set_operation_callback |
( |
std::function< int(memory< SIZE, BUSWIDTH > &, tlm::tlm_generic_payload &, sc_core::sc_time &delay)> | cb | ) |
|
|
inline |
allows to register a callback or functor being invoked upon an access to the memory
- Parameters
-
| cb | the callback function or functor |
Definition at line 100 of file memory.h.
template<unsigned long long SIZE, unsigned BUSWIDTH = LT, unsigned PAGE_ADDR_BITS = 24, bool USE_CYCLES = false>
| void scc::memory< SIZE, BUSWIDTH, PAGE_ADDR_BITS, USE_CYCLES >::unmap_host_memory |
( |
uint64_t | base, |
|
|
uint64_t | size ) |
|
inline |
unmpas a host memory mapped into the address range of the TLM memory
- Parameters
-
| base | base address where the memory shall be mapped |
| size | size of the memory range to map |
Definition at line 145 of file memory.h.
